Drehbarer Pulverisierer RP-IT
Modell | RP10 | RP16 | RP20 | RP30 | RP40 | RP50 | RP80 |
Empf. Baggergewicht (t) | 10-18 | 16-20 | 18-26 | 26-32 | 32-45 | 45-60 | 60-90 |
Gewicht (kg) | 1100 | 1700 | 2000 | 2850 | 4100 | 5200 | 8200 |
Öffnungsweite (mm) | 580 | 700 | 750 | 900 | 1000 | 1100 | 1250 |
Betriebsdruck (bar) | 300-350 | 300-350 | 300-350 | 300-350 | 300-350 | 300-350 | 300-350 |
Empf. Ölmenge (l/min) | 100-180 | 130-150 | 180-200 | 200-220 | 220-280 | 335-375 | 500-600 |
Rotationsdruck (bar) | 190-200 | 130-150 | 130-150 | 100-115 | 100-115 | 100-115 | 140-150 |
Rotation empf. Ölmenge (l/min) | 10-15 | 30-40 | 30-40 | 30-40 | 30-40 | 30-40 | 50-60 |
Kraft Spitze (t) | 46 | 55 | 71 | 84 | 118 | 144 | 230 |
Kraft Mitte (t) | 72 | 85 | 110 | 130 | 189 | 238 | 361 |
Kraft Schneide (t) | 159 | 207 | 268 | 262 | 372 | 543 | 787 |
